Rackmount Standard |
|
Construction: |
Heavy Duty Cold Rolled Electroplated Steel |
|
Color: |
Black (Standard), Beige or Custom |
|
System Boards: |
Pentium 4, Dual Xeon, AMD 64, Dual Opteron |
|
Motherboard Size: |
Support EATX M/B (Max. to 12" x 13") |
|
Drive Bays: |
1x 5.25", Slim CDROM, 1x 3.5¡± Open, 3x
3.5¡± |
|
Power Supply: |
(Rear Chassis Installation) Single or 2U
Redundant Power (Optional) Max Depth 300mm |
|
Cooling Units: |
3x (80mm = 42.5CFM ea.) Ball Bearing Fan
plus
1x Rear Exhaust Blower Fan (Optional) |
|
Expansion Slot: |
3x Slot Horizontal OR 7x
Vertical Low Profile PCI Slots |
|
Connector Port (front):
|
2x USB |
|
Indicators: |
LEDs for Power, 32x HDD Activity, 3x LAN,
Fan Failure, Temperature Warning |
|
Buttons: |
Power On/Off Momentary (Thin Rocker)
Switch, System Reset |
|
Crossbar: |
2U Riser PCI Spanner Bar (for riser card) |
|
Front Door(s): |
Removable Single Door with 2x Thumbscrew |
|
Air Filter: |
Inside
Front Panel (Washable) |
|
Dimensions:
(W x H x D): |
483(W) x 88(H) x 526(D)
mm (19" x 3.5" x 20.7") |
|
Humidity: |
5% - 95% Non-condensing |
|
Product Applications: |
Standard
Server Box, Decoder, Encoder |
|
|
